2A11 aluminum square bar round bar

2A11 aluminum alloy is the earliest hard aluminum used, generally called standard hard aluminum, with medium strength. It has good plasticity in annealing, quenching and hot state. It can be heat-treated and strengthened. It can be used in quenching and natural aging conditions. The weldability is good, and there is a tendency to crack when performing gas welding and argon arc welding; the cutting is good in the quenching aging state and is poor in the annealing state.

Henan chalco aluminum 2A11 aluminum square bar round bar performance:
Tensile strength σb (MPA): ≥370
Conditional yield strength σ0.2 (MPA): ≥215
Elongation δ5 (%): ≥12
(Note: longitudinal mechanical properties of bar at room temperature, sample size: bar diameter (square bar, hexagonal bar inscribed circle diameter) ≤ 150)



Henan chalco 2A11 aluminum square bar round bar heat treatment process:
1) Homogenization annealing: heating 480 ~ 495 ° C; holding 12 ~ 14h; furnace cooling.
2) Complete annealing: heating 390 ~ 430 ° C; holding time 30 ~ 120min; air cooling.
3) Rapid annealing: heating 350 ~ 370 ° C; holding time is 30 ~ 120min; air cooling.
4) Quenching and aging: quenching 495 ~ 510 ° C, water cooling; artificial aging 155 ~ 165 ° C, 6 ~ 10h, air cooling; natural aging: room temperature 96h.

 2A11 aluminum square bar round bar temper: 2A11 aluminum extruded rod (≤150mm, H112, T4 state)
2A11 aluminum alloy square bar  round bar supplied by Henan Chalco Aluminum Products are strictly in accordance with GB/T3191-2010, GB/T6892-2006, GB/T3190-2008 and other national standards for production to ensure the excellent quality of products. The product can be customized according to the special requirements of the customer.
