aluminium tubular busbar

Aluminium tubular bus bar is one of the leading products of the bus, and it is one of the key equipment (materials) in the power transmission and transformation system. It plays a vital role in the safe and reliable operation of the transmission and transformation system and power equipment.

SIGNI aluminum tubular bus bar specification
Alloy: 6101B 6063
Status: T4 T5 T6
Thickness: 5mm~100mm
Outer diameter: 10mm~500mm
Length: 1000~15000mm

Aluminium tubular bus bar
1) Aluminium tubular busbar adopts a series of advanced technologies such as domestic advanced hot-top casting seamless tubes, with smooth surface, high dimensional accuracy, high tensile strength, and resistance to discharge and deformation;
2) Aluminum tubular busbar, with excellent processing, welding, electrical conductivity and heat resistance.
3) Good convection heat dissipation conditions, low temperature rise, low loss, strong conductivity and large current carrying capacity
4) High heat resistance, which can increase the working temperature of the tube bus (working temperature reaches 150℃-200℃), the conductor has high mechanical strength at high temperature, and improves the safety and reliability of the power transmission and transformation system
5) The installation area is small, and the combined tube bus bar is 1/3 of the area of ​​the flexible conductor;
6) Anti-corrosion, not easy to coat, strong disaster resistance, long service life
7) Convenient installation, beautiful appearance, safe, stable and reliable operation, easy for maintenance and repair
