6082 Aluminium Flat Bus Bar
Author:Frank Time:2023-05-05
Aluminium Flat BarThe 6082 T6 grade is of a general engineering specification and one of the most commonly used alloys in the UK. Being strong and resistant to corrosion, it is ideal for machining and light engineering.
We supply a large variety of aluminium flat bar in both imperial and metric measurements. With all sizes, we offer a variety of lengths enabling you to pick a size nearest to what you require.
|
|
|---|
Place of Origin : Henan China(Mainland)
Application of Aluminum Bars :
Aluminum bars can be used in aircraft structures, rivet, missile components, truck wheel hub, screw propeller and other structural components.
Technical Parameters :
Alloy:6060 , 6061, 6063, 6082,
Standard :
GB/T3191,ASTM B221,211,BS1474,ISO209, EN573,JISH4000
Grade :
1,2,3,5,6,7 series.
Temper : H112, T4, T6, T651,T6510
Chemical Properties
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Ga | V | Others |
Aluminium min. |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Each | Total | |||||||||||||
| 6082 | 0.7-1.3 | 0.5 | 0.1 | 0.4-1.0 | 0.6-1.2 | 0.25 | - | 0.2 | 0.1 | - | - | 0.05 | 0.15 | Remainder |
Mechanical properties according to EN755-2
| Temper* |
Thickness e** |
Yield stress Rp0.2 (mpa) |
Tensile strength Rm (mpa) |
Elongation A[%] |
Elongation A50mm [%] |
Hardness ** HB |
|---|---|---|---|---|---|---|
| T4 | e<=25 | 110 | 205 | 14 | 12 | 65 |
| T5 | e<=5 | 230 | 270 | 8 | 6 | 80 |
| T6 | E<=5 | 250 | 290 | 8 | 6 | 95 |
|
5 |
260 | 310 | 10 | 8 | 95 |
Physical properties (approximate values, 20℃)
|
Density [kg/m3] |
Melting range [℃] |
Electrical Conductivity [MS/m] |
Thermal Conductivity [W/m.K] |
Co-efficient of Thermal expansion 10-6/k |
Modulus of elasticity [GPa] |
|---|---|---|---|---|---|
| 2700 | 585-650 | 24-32 | 170-220 | 23.4 | ≈70 |
Properties
Aluminium and Copper Specifications
| Parameters | Aluminium | Copper |
|---|---|---|
| Relevant Standards |
IEC 60105 ISO 209-1,2 |
IEC 60028 |
|
Physical Properties Chemical Composition Specific Heat gm.cal/℃ Density gm/cm2 Melting Point ℃ |
0.092 2.91 660 |
99% pure 0.220 8.89 1083 |
|
Mechanical Properties Ultimate Tensile Strength kgf/mm2 Ultimate Shearing Strength kgf/mm2 Elastic Modulus kgf/mm2 0.2% Tensile-proof Strength kgf/mm2 |
20.5/25 15 6,700 16.5/22 |
22-26 16-19 12000 60-80% of tensile strength |
|
Electrical Properties Specific Resistance ʋʊcm Volume Conductivity ʋʊmm2 Conductivity % IACS Co-efficient of expansion mm/m/℃ |
3.133 31.9 57 2.3*10-5 |
1.7241 58 100 1.73*10-5 |
Packaging & Delivery
Packaging Details :
1. Standard packing: plastic sheet wrapped for each product in order to protect surfaces,craft paper wrapped in bundles.
2. Special packing: wooden cases
3. Customized packing methods are welcomed.
Delivery Detail : 7-15days
